Main parameter

Image Sensor

1/2.8” Progressive Scan CMOS

Signal Type

Network signal

Minimal Illumination

Color: 0.001 Lux @(F1.6, AGC ON); Black and white: 0.0005Lux @(F1.6, AGC ON)

Main Stream Resolution

50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)

60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Shell Material

Optional stainless steel/Titanium alloy/Industrial plastic

Waterproof Level

0-100 meters

Voltage Supply

24VDC (Voltage optional)

Working Temperature

-30℃～+60℃

Size

Φ128*252mm (Not including parts 37mm connector )

Packing List

Cable, Adaptor, Warranty card, Certification, Report

Customization

Depth

Sensor (Temperature, Pressure...)

Control display terminal
