Main parameter

Image Sensor

1/1.7" Progressive Scan CMOS

Chip

Hass Chip Hi3519V101

Electronic Shutter

1/25s~1/10000s

SIGNAL-NOISE RATIO

≥50dB (AGC OFF)

Wide Dynamic Range

≥80dB

Signal Type

Network Signal Info

DPI

4000×3000

Minimal Illumination

0.0001Lux@F1.2

Material

Stainless steel/Titanium alloy/Technology of plastics

Waterproof Level

0-300 meters（Deepest 6000m）

Voltage Supply

12VDC, 24VDC, 36VDC (Optional)

Temperature

-30℃～+60℃

Size

Φ70*237mm（200+37mm parts）

Customization

Depth(The deepest can do 6000M)

Sensor (Temperature、Pressure...)

Control display terminal
