Main Parameters

Image Sensor

2 million coaxial HD COMS/1080p

Signal Type

Coaxial HD

DPI

2 million pixels

SYS

PAL/NTSC optional

Minimal Illumination

0.01 lux at F1.2 5600°K

Video Output

1V‐75 ohms AHD video signal （Anti-interference technology）

Rotation Range

Horizontal direction 360° continuous rotation, vertical direction 0°～180°

Antenna Sweep Radius

Maximum in air：10m   Minimum in air：80mm

Material

Stainless steel/Titanium alloy

Waterproof Level

0-100 meters

Operating Temperature

-20℃ ~ +60℃

Size

Φ55*164 (not including parts 34mm connector)

Customization

Depth

Sensor （Temperature、Pressure...）

Control display screen
